LCR-T4 ESR Meter

LCR-T4 ESR Meter Transistor Tester Diode Triode Capacitance SCR Inductance. Features: - Widely used for detecting NPN and PNP transistors, capacitors, resistors, diodes, triodes, N-channel and P-channel MOSFETs, IGBT, JFET, triacs, batteries, etc. - Can also be used to detect infrared waveforms. - Can detect Zener diodes and has a self-calibration function. - After detection, align the infrared remote control with the IR light and press the button on the remote. If the detector decodes it successfully, it will display the data code and infrared waveform. - One-button operation, automatic detection and shutdown. - Place component pins in the corresponding area, flip the small handle, and the detector will test it automatically; results are clearly displayed on the TFT screen. - Color display. Specifications: - Display: 1.8-inch TFT - Resolution: 160x128 - Diode range: <4.5V - Zener diode detection area: 0.01-4.5V - Zener area: 0.01-30V - Triac range: IGT <6mA - Capacitance: 25pF-100mF - Resistance: 0.01-50MOhm - Inductance: 0.01mH-20H - Battery: 0.1-4.5V - Power supply: Rechargeable lithium battery (included) - Dimensions: 8.8x8x2.8 cm - Weight: 111.5g Delivery: - Delivery to 20 Yanvar is possible for 2 AZN. - Delivery available to Sumgayit, Khirdalan, and Baku. - Shipping to regions via post is possible. - Whatsapp is active. - You can view our other ads in the "All ads of the user" section.
