Soil Penetrometer GTJ-EVD Dynamic Deformation Modulus

Soil Penetrometer Model: GTJ-EVD Dynamic Deformation Modulus Tester (EVD) The tester is designed to measure the deflection (settlement) of road bases and soils under dynamic load. The results obtained allow for the assessment of the bearing capacity and deformation characteristics of the soil and base. GTJ-Evd is used for construction quality control and soil base testing in the following construction works: railways, highways, airports, urban transport facilities, ports, bridges, industrial buildings, civil buildings, and structures. The tester is particularly convenient for testing in narrow and inaccessible areas, including bridge and culvert transition zones, road shoulders, and existing foundations. The operating principle of the device is based on creating a dynamic load using a falling weight. The device measures the resulting surface settlement and automatically calculates the dynamic deformation modulus Evd. Using dynamic loading allows for the simulation of the impact of road loads on the subgrade. The device ensures rapid testing - measuring one point takes approximately 35 seconds. GTJ-Evd is equipped with imported sensors and electronic components to ensure high measurement accuracy. The handheld device features a backlit LCD display with Chinese/English language options for easy operation in various lighting conditions. The device automatically calculates the Evd value and displays the measurement results as numerical values and curves. Data can be stored in the device's internal memory, transferred to a computer via a data transfer interface, and printed directly on-site using a Bluetooth microprinter. The device is suitable for testing various types of soil and soil-rock mixtures, provided that the particle size does not exceed 1/4 of the diameter of the loading plate. 📌 Specifications ● Model: GTJ-EVD ● Device Type: Dynamic deformation modulus device. ● Measurement principle: Manual falling weight deflectometer. ● Measured parameter: Dynamic deformation modulus EVD. ● Evd measurement range: 10–225 MPa. ● Test impact depth range: 0–500 mm. ● Applicable soil types: Various soil types and soil-rock mixtures. ● Maximum particle size: Not more than 1/4 of the loading plate diameter. ● Operating temperature: -10°C to +40°C. ● Operating humidity: Less than 90% RH. ● Total weight of loading device: 15 kg. ● Falling weight: 10 kg. ● Drop height: 700 ± 20 mm. ● Maximum impact force: 7.07 kN. ● Impact duration: 18 ± 1 ms. ● Loading plate weight: 15 kg. ● Loading plate diameter: 300 mm. ● Loading plate thickness: 20 mm. ● Settlement measurement range: 0.10–2.00 mm. ● Memory capacity: 2000 groups of measurement data. ● Screen size: 3 inches. ● Handheld unit dimensions: 100×205×40 mm. ● Handheld unit weight: 0.8 kg. ● Power type: High-capacity lithium battery. ● Operating time: More than 18 hours. ● Screen: LCD. ● Interface Languages: Chinese / English. ● Screen Backlight: Yes. ● Automatic EVD calculation: Yes. ● Measurement curve display: Yes. ● Measurement speed: Approximately 35 seconds per point. ● Data transfer: Via data cable. ● Computer connection: USB interface. ● Result printing: Bluetooth microprinter. ● Printing type: Wireless Bluetooth printing. ● Main body material: Engineering plastic. ● Main body size: 420 × 140 × 335 mm. ● Main body weight: 4.5 kg. ● Outer case material: Aluminum alloy. ● Outer case size: 1120 × 400 × 380 mm. ● Package contents: - Main unit (handheld unit): 1 pc. - Microprinter: 1 pc. - Printer charger: 1 pc. - Printing paper: 10 pcs. - Sensor signal cable: 1 pc. - Mini-USB cable: 1 pc. - Main unit charger 8.4 V / 2 A: 1 pc. - User manual: 1 pc. - Demo CD: 1 pc. - Software/accessory CD: 1 pc. - Aluminum carrying case: 1 pc. - Weight set: 1 set. - Towel: 1 pc. - Maintenance oil: 1 pc. bakutool.az
