HAUG Neptune

Reliable compressor for all types of gases The HAUG Neptune series is used for compressing all types of gases. Using a magnetic coupling, individual customer requirements and explosion-proof requirements can be met. • Completely oil-free and dry-running piston compressor • Permanent technical tightness due to magnetic coupling • Environmentally friendly as it is oil-free, gas-tight, and efficient • Compressor leakage rate: < 0.001 mbar·l/s • Air-cooled • Rotation speed: 970 – 1450 rpm • Modular cylinder configuration with cylinder diameter up to 100 mm • 2 or 3 cylinder versions, 1-, 2- or 3-stage compression • Explosion-proof compressor (ATEX zone 1 or zone 2 compliant) • Very robust and long-lasting construction • Suitable for compact and foundation-free installation Suction pressure: maximum 13 bar(g) Pressure: maximum 100 bar(g) Volume flow: 50 Nm³/h Volume flow (Booster version): 100 Nm³/h Rated power: 2.0 – 7.5 kW Medium: all types of gases Features Oil-free Completely oil-free and dry-running piston compressor Magnetic coupling The wear-resistant magnetic coupling between the compressor and motor ensures both hermetic gas tightness and extremely low maintenance, operating with maximum reliability. ATEX variant available Solutions compliant with ISO 80079-34:2020 standard and European ATEX directive 2014/34/EU. Hermetic gas-tight Reliable, hermetic gas-tight compressor design ensures no gas escapes and ambient air/gas does not contaminate the compressed medium. High-efficiency air cooling Proven and easy-to-maintain design with high cooling performance.
